Access Point UBIQUITI WI-FI 7 GATEWAY CLOUD UBIQUITI UX7-EU UNIFI 1P LAN X2.5GBE RJ45 1P WAN X1 10 GBE RJ45 PORTE: 2 x RJ-45,ALIMENTAZIONE: CC BANDA WIRELESS: 2.4 GHz, 5 GHz, 6 GHz
| Prezzo: | €231,20 Iva inclusa (22%) |
|---|---|
| Cod. art.: | 25155 |
| Marca: | Ubiquiti |
| Disponibilità: | Ordinabile (2/4 giorni lav.) |
| Quantità: |
Servizi
StampaDescrizione
Overview
Dimensions: 117 x 117 x 42.5 mm (4.61 x 4.61 x 1.67'')
UniFi Application Suite: Network: ?
Managed UniFi Devices: 30
Simultaneous Users Connected: 300
Default WAN Ports: 1x 10 GbE RJ45
LAN Ports: 1x 2.5 GbE RJ45
IDS/IPS Throughput: 2.3 Gbps
Form Factor: Compact desktop
Security
Stateful Firewall: ?
Application-Aware Layer 7 Firewall: ?
DPI & Traffic Identification: ?
Zone-Based Firewall Advanced Filtering (Regions, Domains, Apps): ?
Content Filtering: ?
Intrusion Prevention (IPS/IDS): ?
Ad Blocking: ?
IDS/IPS Signatures: 20,000+ with CyberSecure
VLAN/Subnet-based Traffic Segmentation: ?
VPN & SD-WAN
License-Free SD-WAN: ?
Site-to-Site VPN:
- Site Magic: ?
- IPsec: ?
- OpenVPN: ?
VPN Server:
- Identity Endpoint One-Click VPN: ?
- Teleport Zero-Configuration VPN: ?
- WireGuard: ?
- OpenVPN: ?
- L2TP: ?
VPN Client:
- OpenVPN: ?
- WireGuard: ?
Networking
Dynamic Routing: OSPF: ?
Advanced QoS: ?
Multicast DNS (mDNS): ?
Advanced NAT (SNAT / DNAT / Masquerade / NAT Pooling / 1-to-1 NAT): ?
Integrated RADIUS Server: ?
RADIUS over TLS (RadSec): ?
Additional Internet Failover with UniFi LTE Backup: ?
Internet Quality and Outage Reporting: ?
Policy-based WAN and VPN Routing: ?
Customizable DHCP Server: ?
IPv6 ISP Support: ?
IGMP Proxy: ?
Integrated WiFi
WiFi Standard: 802.11a/b/g/n/ac/ax/be (WiFi 6/6E, WiFi 7)
Throughput:
- 6 GHz: 5.7 Gbps
- 5 GHz: 4.3 Gbps
- 2.4 GHz: 688 Mbps
MIMO:
- 6 GHz: 2 x 2 (DL/UL MU-MIMO)
- 5 GHz: 2 x 2 (DL/UL MU-MIMO)
- 2.4 GHz: 2 x 2 (DL/UL MU-MIMO)
Antenna Gain:
- 6 GHz: 6 dBi
- 5 GHz: 7 dBi
- 2.4 GHz: 4 dBi
Wireless Security: WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3/PPSK)
Max. BSSIDs:
- 4 per Radio (Gateway Mode)
- 4 per Radio (AP Mode)
Supported Data Rates:
- 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
- 802.11b: 1, 2, 5.5, 11 Mbps
- 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
- 802.11n: 6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40)
- 802.11ac (WiFi 5): 6.5 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80/160)
- 802.11ax (WiFi 6/6E): 7.3 Mbps to 2.4 Gbps (MCS0 - MCS11 NSS1/2, HE 20/40/80/160)
- 802.11be (WiFi 7): 7.3 Mbps to 5.7 Gbps (MCS0 - MCS13 NSS1/2, EHT 20/40/80/160/240/320)
Hardware
Max. Power Consumption: 22W
Power Method: USB type C (5V DC/5A)
Power Supply: USB type C (5V DC/5A) (Adapter included)
Max. TX Power:
- 6 GHz: 24 dBm
- 5 GHz: 26 dBm
- 2.4 GHz: 23 dBm
Supported Voltage Range: 100-240V AC
Processor: Quad-core ARM® Cortex®-A53 at 1.5 GHz
System Memory: 3 GB
Weight: 422 g (14.9 oz)
Enclosure Material: Polycarbonate
LCM Display: 0.96" status display
Management:
- Ethernet
- Bluetooth
LEDs: Ethernet: ?
ESD/EMP Protection: Air: ± 8kV, contact: ± 4kV
Ambient Operating Temperature: -10 to 40° C (14 to 104° F)
Ambient Operating Humidity: 5 to 95% noncondensing
Certifications: CE, FCC, IC
Button: 1x Factory-reset
Software
VLAN: 802.1Q
Guest Traffic Isolation: ?
