GATEWAY INDUSTRIALE LTE MIKROTIK EC25-EU&KNE KNOT EMBEDDED LTE4 CON SUPP. BLUETOOTH E GNSS
| Prezzo: | €77,70 Iva inclusa (22%) |
|---|---|
| Cod. art.: | 12419 |
| Marca: | Mikrotik |
| Disponibilità: | Ordinabile (2/4 giorni lav.) |
| Quantità: |
Servizi
StampaDescrizione
Specifications
Product code: EC25-EU&KNe
Architecture ARM 32bit
CPU: CPU ARM32-bit Cortex A7 up to 1.2 GHz
CPU core count: 1
CPU nominal frequency: 1200 MHz
RouterOS license: 3
Operating System: RouterOS v7
Size of RAM: 256 MB
Storage size: 512 MB
Storage type: NAND
MTBF: Approximately 100'000 hours at 25C
Tested ambient temperature: -40°C to 70°C
Powering
Number of DC inputs: 2 (PoE-IN, USB-C)
Max power consumption: 7 W
Max power consumption without attachments: 7 W
PoE in: 802.3af/at
Cooling type:Passive
PoE in input Voltage: 12-57 V
USB C input Voltage: 5 V
Mobile
2G Category: Class12
2G bands:
- 3 (1800MHz)
- 8 (900MHz)
3G Category: R8 (42.2Mbps Downlink, 5.76Mbps Uplink)
3G bands:
- 1 (2100MHz)
- 8 (900MHz)
LTE Category: 4 (150Mbps Downlink, 50Mbps Uplink)
MIMO DL: 2x2
MIMO UL: 1x1
LTE FDD bands:
- 1 (2100MHz)
- 3 (1800MHz)
- 7 (2600MHz)
- 8 (900 MHz)
- 20 (800MHz)
- 28A (700 MHz)
LTE TDD bands:
- 38 (2600MHz)
- 40 (2300MHz)
- 41 (2500MHz)
TAC: 86554604
Ethernet
10/100/1000 Ethernet ports: 1
Number of 1G Ethernet ports with Reverse PoE (PoE-in): 1
Peripherals
Number of SIM slots: 1 Modem (Nano SIM)
Other
CPU temperature monitor: Yes
Bluetooth version: 5.1
GPS RF connector type: SMA
eSIM: Yes
Certification & Approvals
Certification: CE, EAC, ROHS
IP: 20
Included parts
K-91 Fastening Set
5 V 0.8 A Power adapter
Note
The device has an operating system preinstalled and licensed. No separate purchase is necessary and the product is ready to use. The device includes free software updates for the life of the product or a minimum of 5 years starting from date of purchase.
