HUB SWITCH 48P POE LAN GIGABIT UBIQUITI USW-PRO-MAX-48-POE L3 16P 2.5GBE (8P POE++ 8P POE+) 24P GBE POE+ 8P POE++ - 720W,PORTE LAN: 48, PORTE SFP: 4,POE: Sì , GESTIONE: Managed ,MONTAGGIO RACK: Sì
| Prezzo: | €1.313,20 Iva inclusa (22%) |
|---|---|
| Cod. art.: | 25163 |
| Marca: | Ubiquiti |
| Disponibilità: | Ordinabile (2/4 giorni lav.) |
| Quantità: |
Servizi
StampaDescrizione
Mechanical
Dimensions: 442.4 x 400 x 44 mm
Weight:
- Without mounting brackets: 6.2 kg
- With mounting brackets: 6.3 kg
Enclosure material: SGCC steel
Hardware
Management interface: Ethernet In-Band
Networking interface:
- 32x GbE RJ45 ports
- 16x 1/2.5 GbE RJ45 ports
- 4x 10G SFP+ ports
PoE interface:
- 32x PoE/PoE+ (Pins 1, 2+; 3, 6-)
- 16x 60W PoE++ (Pair A 1, 2+; 3, 6-) (Pair B 4, 5+; 7, 8-)
Total non-blocking throughput: 112 Gbps
Switching capacity: 224 Gbps
Power method:
- 1x Universal input, 100—240V AC, 50/60 Hz
- 1x USP-RPS DC input
Power supply: AC/DC, internal, 820W
Supported voltage range: 100—240V AC
Max. power consumption: 100W (Excluding PoE output)
Total available PoE: 720W
Max. PoE wattage per port by PSE:
- PoE: 15.4W
- PoE+: 30W
- PoE++: 60W
Voltage range PoE mode:
- PoE: 44—57V
- PoE+: 50—57V
LCM display: 1.3" touchscreen
Button: Factory reset
Operating temperature: -5 to 40° C (23 to 104° F)
Operating humidity: 10 to 90% noncondensing
Certifications: CE, FCC, IC
Etherlighting™
Ethernet:
- Locating
- Speed/link
- Native VLAN/network
SFP+:
- Locating
- Speed/link
- Native VLAN/network
LEDs
System: Status
RPS: Status
Application Requirements
UniFi Network: Version 8.0.24 and later
