HUB SWITCH UBIQUITI 24P POE LAN GIGABIT USW-PRO-MAX-24-POE L3 8P 2.5GBE POE++ 8P GBE POE+ 8P POE++ - 400W,PORTE SFP: 2 POE: Sì GESTIONE: Managed MONTAGGIO RACK: Sì
| Prezzo: | €897,20 Iva inclusa (22%) |
|---|---|
| Cod. art.: | 25153 |
| Marca: | Ubiquiti |
| Disponibilità: | Ordinabile (2/4 giorni lav.) |
| Quantità: |
Servizi
StampaDescrizione
Mechanical
Dimensions: 442 x 325 x 44 mm
Weight:
- Without mounting brackets: 5.1 kg
- With mounting brackets: 5.2 kg
Enclosure material: SGCC steel
Hardware
Management interface: Ethernet In-Band
Networking interface:
- 16x GbE RJ45 ports
- 8x 1/2.5 GbE RJ45 ports
- 2x 10G SFP+ ports
PoE interface:
- 8x PoE/PoE+ (Pins 1, 2+; 3, 6-)
- 16x 60W PoE++ (Pair A 1, 2+; 3, 6-) (Pair B 4, 5+; 7, 8-)
Total non-blocking throughput: 56 Gbps
Switching capacity: 112 Gbps
Power method:
- 1x Universal input, 100—240V AC, 50/60 Hz
- 1x USP-RPS DC input
Power supply: AC/DC, internal, 450W
Supported voltage range: 100—240V AC
Max. power consumption: 50W (Excluding PoE output)
Total available PoE: 400W
Max. PoE wattage per port by PSE:
- PoE: 15.4W
- PoE+: 30W
- PoE++: 60W
Voltage range PoE mode:
- PoE: 44—57V
- PoE+: 50—57V
LCM display: 1.3" touchscreen
Button: Factory reset
Operating temperature: -5 to 40° C (23 to 104° F)
Operating humidity: 10 to 90% noncondensing
Certifications: CE, FCC, IC
Etherlighting™
Ethernet:
- Locating
- Speed/link
- Native VLAN/network
SFP+:
- Locating
- Speed/link
- Native VLAN/network
LEDs
System: Status
RPS: Status
Application Requirements
UniFi Network: Version 8.0.24 and later
Dimensions: 442 x 325 x 44 mm
Weight:
- Without mounting brackets: 5.1 kg
- With mounting brackets: 5.2 kg
Enclosure material: SGCC steel
Hardware
Management interface: Ethernet In-Band
Networking interface:
- 16x GbE RJ45 ports
- 8x 1/2.5 GbE RJ45 ports
- 2x 10G SFP+ ports
PoE interface:
- 8x PoE/PoE+ (Pins 1, 2+; 3, 6-)
- 16x 60W PoE++ (Pair A 1, 2+; 3, 6-) (Pair B 4, 5+; 7, 8-)
Total non-blocking throughput: 56 Gbps
Switching capacity: 112 Gbps
Power method:
- 1x Universal input, 100—240V AC, 50/60 Hz
- 1x USP-RPS DC input
Power supply: AC/DC, internal, 450W
Supported voltage range: 100—240V AC
Max. power consumption: 50W (Excluding PoE output)
Total available PoE: 400W
Max. PoE wattage per port by PSE:
- PoE: 15.4W
- PoE+: 30W
- PoE++: 60W
Voltage range PoE mode:
- PoE: 44—57V
- PoE+: 50—57V
LCM display: 1.3" touchscreen
Button: Factory reset
Operating temperature: -5 to 40° C (23 to 104° F)
Operating humidity: 10 to 90% noncondensing
Certifications: CE, FCC, IC
Etherlighting™
Ethernet:
- Locating
- Speed/link
- Native VLAN/network
SFP+:
- Locating
- Speed/link
- Native VLAN/network
LEDs
System: Status
RPS: Status
Application Requirements
UniFi Network: Version 8.0.24 and later
